Bioimaging Centre

Within the Bioimaging Centre in the School of Engineering and Materials Science we have the following two confocal microscope systems: firstly a Nikon CSU-W1 SoRa spinning disk confocal, secondly a Nikon AX R NSPARC confocal  with Crest Optics X-Light V3 spinning disk and Brillouin mechano-spectroscopy system, as well as two inverted epifluorescence microscopes: Leica DMi8 & Leica DMI4000B, and an incubator based Lumascope 720 for live cell imaging. We also have a Nanosight LM20 for size distribution of particles, an upright Jenapol Polarized Microscope, an iBright FL1500 for western blots and nucleic acid gels, and Imaris 9.7.2 workstation for imaging data analysis. The bioimaging facilities have contributed significantly to the publication output in SEMS, other schools at QMUL and other institutes across UK. To apply for a training of any of our bioimaging facilities, please follow the training request procedures.

Nikon AX R NSPARC confocal  with Crest Optics X-Light V3 spinning disk and Brillouin

Nikon AX R with NSPARC

Nikon AX R NSPARC confocal  with Crest Optics X-Light V3 spinning disk and Brillouin is a combination of an inverted AX R laser scanning confocal microscopy with NSPARC (Nikon Spatial Array Confocal), a Crest Optics X-Light V3 spinning disk confocal microscope and Brillouin mechano-spectroscopy system. Nikon AX R confocal with NSPARC  detector enables super resolution imaging beyond the diffraction limit at 100 nm; Crest Optics Brillouin mechano-spectroscopy measures the Brillouin shift of a laser beam interacting with micro-acoustic waves originating from material, which are a function of mechanical properties. Hence the equipment has the unique capacity to measure stiffness and viscosity inside of cells, tissues, organoids or organ-on-a-chip constructs; while the Crest Optics X-Light V3 spinning disk confocal microscope integrates with the Brillouin mechano-spectroscopy for correlative confocal bioimaging and mechanical characterisation.  The 3-in-1 system contains a laser safety interlocked full enclosure incubator with temperature, CO2 and humidity control for live cell imaging, FRAP, FRET. The system uses NIS-Elements software for data acquisition and image processing, and it comes with an offline data processing workstation.

Objectives:

  • Plan Apochromat Lambda D 4x air lens – N.A 0.2, WD 20 mm
  • Plan Apochromat Lambda D 10x air lens – N.A. 0.45, WD 4 mm
  • Plan Apochromat Lambda D 20x air lens – N.A. 0.8, WD 0.8 mm
  • S Plan Fluor ELWD 40XC – NA 0.6, WD 3.6-2.8 mm
  • Plan Apochromat Lambda D 60x oil lens – N.A. 1.42, 0.15 mm
  • Plan Apochromat Lambda D 100x oil lens – N.A. 1.45, 0.13 mm
  • Plan Apochromat Lambda S 25XC Sil – NA 1.05, WD 0.55 mm
  • Plan Apochromat Lambda S 60XC Sil – NA 1.30, WD 0.3 mm

Lasers:

  • Nikon AX R confocal with NSPARC confocal: a Lumencor LUA-S6 includes diode laser lines of 405 nm, 445 nm, 488 nm, optically pumped semiconductor laser (OPSL) lines of 514 nm and 561 nm, and a diode laser line of 640 nm, with 19 mW output power for each laser line. It also contains a Omicron-Laserage 30 mW LaserNest 730 nm diode laser line.
  • Crest Optics X-Light V3 spinning disk confocal: a Lumencor Celestra Quattro laser bed, which provides ~800mW output power across 405 nm, 477 nm, 546 nm and 638 nm diode laser lines.
  • Crest Optics Brillouin mechano-spectroscopy: a 4 W TOPTICA frequency-stabilized 780 nm external cavity diode laser (ECDL) locked to the Rubidium D2 line.

Cameras:

  • Two Photometrics Kinetix22 high-speed, back-illuminated sCMOS cameras

SOP Nikon AX R NSPARC confocal  with Crest Optics X-Light V3 spinning disk and Brillouin

Back to the top

Nikon CSU-W1 SoRa Spinning Disk Confocal

Nikon SoRa

Nikon CSU-W1 SoRA Super-Resolution Spinning Disk Confocal scanning unit, couples the Nikon Ti2-E inverted microscope platform to the CSU-W1 SoRa system from Yokogawa. The system is equipped with two camera adapters, disk changer with two spinning disks (a 50 μm pinhole W1 spinning disk, and a 50 μm micro-lensed pinhole SoRa spinning disk), a full enclosure incubator with temperature, CO2 and humidity control for live imaging, FRAP and FRET. The system uses NIS-Elements software for data acquisition and image processing, and it comes with an offline data processing workstation.

Objectives:

  • CFI Plan Fluor 10x/0.3/WD 16mm,
  • CFI Plan Apochromat VC 20x/0.75/WD 1mm,
  • CFI Super Fluor 40xC/0.9/WD 0.34-0.26mm,
  • CFI Plan Apochromat Lambda D 60x/1.42/WD 0.15mm Oil
  • CFI Apochromat TIRF 60xC/1.49/WD 0.12mm Oil

Lasers:

  • Omicron-Laserage LuxX Diode lasers: 405nm (120mW), 445nm (100mW), 488nm (200mW), 515nm (100mW), 638nm (200mW)
  • Coherent OBIS LS laser 561nm (150mW)

Camera:

  • Two Photometrics Prime BSI back-illuminated sCMOS cameras

SOP Nikon CSU W1 SoRa

Back to the top

Leica DMI4000B Epifluorescence Microscope

Leica DMI4000B

Leica DMI4000B is an inverted epifluorescence widefield (WF) microscope suitable for bright field (BF), phase contrast (PH) acquisition and epifluroscence imaging with DAPI, FITC, TRITC, Texas Red and Cy5 filters on fixed cell and tissue samples.

Objectives:

  • N PLAN 2.5x/0.07
  • HCX PL FLUOTAR 10x/0.3 PH1,
  • HCX PL FLUOTAR 20x/0.5 PH2,
  • HCX PL APO 40x/1.25-0.754 Oil,
  • HCX PL FLUOTAR 63x/1.25 Oil PH3

Camera:

  • LEICA DFC9000 GT sCMOS camera for epifluorescence and BF/PH imaging

SOP Leica DMI4000B

Back to the top

Leica DMi8 Epifluorescence Microscope

Leica DMi8 Chiaro

Leica DMi8 is a semiautomatic inverted epifluorescence widefield (WF) microscope suitable for bright field (BF), phase contrast (PH) acquisition and epifluroscence 2D and 3D imaging with DAPI, GFP, Cy3, and Cy5 filters on fixed cell and tissue samples.

Objectives:

  • HC PL FLUOTAR 10x/0.32 PH1,
  • HC PL FL L 20x/0.40 CORR, PH1,
  • HC PL FL L 40x/0.60 CORR PH2,
  • HC PL FLUOTAR 63X/1.30 Oil PH3

Camera:

  • LEICA K8 sCMOS camera for epifluorescence and BF/PH imaging

SOP Leica DMi8

Back to the top

Lumascope 720

Lumascope 720

Lumascope 720 is an automatic incubator based, inverted 3-colour (blue, green, red) epifluorescence microscope, with motorized XY stage and auto Z-focus. It is suitable for multiple positions, time lapse live imaging with both phase contrast and fluorescence 2D and 3D mode, up to 10 fps, or 30 fps with reduced frame size.

Objectives:

  • Motic EF-N Plan 4x/0.10 (not for imaging),
  • Olympus CAch N 10x/0.25,
  • Olympus LCAch N 20x/0.40,
  • Olympus LCAch N 40x/0.55

Camera:

  • CMOS camera for epifluorescence and PH imaging

SOP Lumascope 720

Back to the top

Nanosight LM20

Nanosight LM20

Nanosight LM20 with a LM10 laser unit (Class 1 diode 635 nm) characterizes the size distribution and concentration of all types of nanoparticles from 20nm-1000nm in solution by dynamically analysing the paths the particles take under Brownian motion over a suitable period of time.

SOP Nanosight LM20

                                                                                                                                                                                                              Back to the top

Jenapol Polarized Microscope

Jenapol Polarized Microscope

Jenapol is an upright polarized microscope with a MC4K 8.3MP Sony IMX334 CMOS camera, using Pixit Pro Version 3.2 software for imaging acquisition, suitable for cultured cells, tissues, mineral or other transparent material samples.

Objectives:

  • Planachromat Pol 10x/0.2,
  • Planachromat Pol 20x/0.4,
  • Planachromat Pol 50x/0.95

Camera:

  • MC4K 8.3MP CMOS camera

SOP Jenapol Polarized Microscope

                                                                                                                                                                                                              Back to the top

 iBright FL1500

                              iBright FL1500

iBright FL1500 Imaging System supports the main imaging applications of fluorescent, chemiluminescent, and colorimetric western blots, in addition to fluorescent stained nucleic acid gels, fluorescent stained protein gels, colorimetric stained protein gels, and colorimetric membrane stains.

Features of the iBright FL1500 Imaging System:
• 9.1 MP cooled CCD camera: high sensitivity and dynamic range to help enable the detection of subtle differences in samples
• Five fluorescence channels: multiplex and capture up to four proteins in a single blot for more meaningful and representative experiments
• Smart Exposure technology: provides rapid determination of optimal exposure time to help minimize the need to repeat exposures to acquire the desired signal
• Simple interface: clear layout of functions and features combined with a 12.1-inch capacitive touchscreen for a smooth imaging experience
• Advanced automated features: automatic sample rotation, automatic zoom, and automatic focus help streamline image capture
• 22.5 x 18.0-cm field of view: large field of view for high-throughput imaging (image up to four mini or two midi blots at a time)
• Green LED-based transilluminator: effectively excite popular DNA dyes such as ethidium bromide and Invitrogen SYBR Green dyes with an alternative to UV-based transilluminators
• Flexible connectivity: export captured images via ethernet connection, Wi-Fi (with optional accessory), USB, or directly to Connect cloud-based platform
• Multiple image analysis options: perform densitometry, quantitation, and normalization directly using the on-instrument software, or for more in-depth analysis use iBright Analysis Software (available in both desktop and cloud-based versions)

                      iBright FL1500 filters

SOP iBright FL1500

                                                                                                                                                                                                              Back to the top

Imaris 9.7.2 ----- Imaris Single Full with ClearView

Imaris 9.7.2

Imaris Single Full gives you complete power and flexibility of all Imaris functionalities at your fingertips. Visualization of complex 3/4D microscopy datasets with automated Spots and Surfaces detection and visualisation (100s of GBs), smart detection of complex objects, tracing of neurons, blood vessels (no lumen) or other filamentous structures, tracking including cell division detection, batch analysis and a wide range of customized analysis powered by MatLab or Python. Imaris integrates ClearView™ algorithms for Spinning Disk Confocal, Widefield Fluorescence, Brightfield, Laser Scanning Confocal and TIRF, allowing GPU-accelerated Deconvolution.

SOP IMARIS

Imaris Quickstart Tutorials

Imaris Reference Manual

For more information:

https://imaris.oxinst.com/products/imaris-single-full

Online learning centre:

https://imaris.oxinst.com/learning/

                                                                                                                                                                                                              Back to the top
